48 Volt / 10Amp / 54.6 Volt (3 Pin Type Connector)
1.⚡ Fast Charging with 48V / 10A output, ideal for lithium-ion batteries.
2.🔒 Auto Cut-Off at 54.6Volt to prevent overcharging and protect battery life.
3.🔌 Secure 3 PIN Connector – reliable fit for most e-scooters.
4.🧠 MCU-Based Smart System – real-time monitoring for voltage, current & temperature.
5.🛡️ Full Protection – safeguards against overvoltage, overcurrent & short circuits.
6.🛡️ Triple-layer safety: Overvoltage, overcurrent & short circuit protected
7.🧾 1 Year Warranty – trusted durability backed by hassle-free support.
8.🇮🇳 Proudly Made in India – engineered for Indian roads, EVs, and climate.add made in india.
Download Brochures
Download
Salient Features
Micro Controller
Based Smart SMPS Charger
Temperature Protection
Over Temperature Protection
Intelligent Charging System
CC-CV (Constant Current - Constant Voltage) charging strategy.
Battery Protection
Battery Reverse Polarity Protection
Short Circuit Protection
preventing damage to electrical components and reducing fire risk.
Voltage Protection
Over Voltage & Over Current Protection
LED Status Indicators
Bright, multicolor LED rings or panels provide intuitive status updates at a glance.
Temperature Control System
Active thermal management keeps performance stable in extreme heat or cold.
Warranty Period
1 Year Warranty
Made
"Proudly Made in India 🇮🇳"
| Input Voltages | ( Low Cut-Off : 180VAC ) & ( High Cut-Off : 280VAC ) |
|---|---|
| Input Current | 6A (±1 A) |
| AC Input Frequency | 47Hz-53 Hz |
| Peak Efficiency | >90% |
| Power Factor | 0.6 @ 230 Vac |
| Rated Power | 850W (±50 W) |
|---|---|
| Maximum DC Output Current | 10A (±1 A) |
| Maximum DC Output Power | 840 W @ 230 Vac |
| Maximum Output Voltage | 54.6V (±0.2 V) |
| Ripple | 20 mV(±10mV) - 300 mA(±10mA) |
| Line Regulation | <2% |
| Load Regulation | <2% |
| Battery Type | LITHIUM-ION |
| Over Current | >=10A+1A |
|---|---|
| Over Voltage | 54.6V (+0.2V) |
| Short Circuit Output | 20A |
| Over Temperature | PROVIDED |
| Reverse battery polarity | PROVIDED |
| DC Output Connector | 3 Pin Type Connector |
|---|---|
| AC Input Connector | 16A 3 PIN Inbuilt Top |
| Input Wire Length | 1500mm (±50mm) |
| Input Wire Copper | 1 SQ mm 3 CORE |
| Output Wire Length | 600mm (±50mm) |
| Output Wire Copper | 3 SQ mm 2 CORE |
| Operating Temperature | 0°C to 50°C |
|---|---|
| Humidity | 5 to 90% non-Condensed |
| Storage Temperature | 0 °C to 50 °C |
| Testing Result at %95 RH@38°C | Passed |
| Enclosure Protection | IP 21 |
|---|---|
| Dimension(L*W*H) | ~(268mmx150mmx70mm) |
| Drop Test Result (If Applicable) | PASS |
| Weight | ~1.700 Kg |
