48 Volt/ 7Amp /58.4 Volt ( 3 Pin Type Connector )
1. The XSTRONG POWER Charger delivers fast and reliable charging with a 48 Volt / 7Amp / 58.4 Volt output.
2. Ideal for lithium batteries. Its Automatic Battery cutt-off at 58.4 Volt prevents overcharging and extends battery life.
3. The 3 PIN Type connector ensures a secure fit for various e-scooters.
4. The MCU-based smart charging system monitors voltage and current to protect against overheating, overcharging, and short circuits.
Crafted with a Durable Aluminium Body, the charger offers excellent heat dissipation and long-lasting use. Built-in safety features guard against overvoltage, overcurrent, and short circuits. Despite its strength, it’s lightweight and portable, making it perfect for home, office, or travel use—keeping your ride powered up wherever you are.
Download Brochures
Download
Salient Features
Micro Controller
Based Smart SMPS Charger
Temperature Protection
Over Temperature Protection
Intelligent Charging System
CC-CV (Constant Current - Constant Voltage) charging strategy.
Battery Protection
Battery Reverse Polarity Protection
Short Circuit Protection
preventing damage to electrical components and reducing fire risk.
Voltage Protection
Over Voltage & Over Current Protection
LED Status Indicators
Bright, multicolor LED rings or panels provide intuitive status updates at a glance.
Temperature Control System
Active thermal management keeps performance stable in extreme heat or cold.
| Input Voltages | ( Low Cut-Off : 180VAC ) & ( High Cut-Off : 280VAC ) |
|---|---|
| Input Current | 2.5A + 0.2A |
| Input Frequency | 50 Hz + 1% |
| Peak Efficiency | >83% |
| Switching Frequency | 50 KHZ |
| Operating Temperature | Standard |
| Input Voltages | ( Low Cut-Off : 180VAC ) & ( High Cut-Off : 280VAC ) |
| Input Current | 2.5A + 0.2A |
| Input Frequency | 50 Hz + 1% |
| Peak Efficiency | >83% |
| Switching Frequency | 50 KHZ |
| Operating Temperature | Standard |
| Maximum Dc Output Voltage | 67.2 V (+0.2V) |
|---|---|
| Maximum Dc Output Current | 7 A (± 0.3 A) |
| Rated Power | 350 W (± 50 W |
| Maximum Dc Output Power | 380 W (± 25 W) |
| Load Regulation | <2% |
| Line Regulation | <2% |
| Battery Type | LITHIUM-ION |
| Over Voltage | 67.2 V (+0.2V) |
|---|---|
| Over Current | >7A+1A |
| Short Circuit Output | Provided |
| Over Temperature | Provided |
| Reverse Battery Polarity | Provided |
| AC Input Connector | 3 PIN Inbuilt 6A-Top |
|---|---|
| DC Output Connector | 3 PIN ( T Type Connector ) |
| Input Wire Length | 1500mm (±50mm) |
| Input Wire Copper | 0.5 SQ mm 3 CORE |
| Output Wire Length | 1500mm (±50mm) |
| Output Wire Copper | 1.5 SQ mm 2 CORE |
| Storage Temperature | 0 °C to 40 °C |
|---|---|
| Operating Temperature | 0 °C to 40 °C |
| Humidity | 5 to 90% non-Condensed |
| Testing Result at %95 RH@38°C | PASSED |
| Enclosure Protection | IP 21 |
|---|---|
| Dimension(L*W*H) | 150L / 150W / 80H ±5mm |
| Cooling | Forced Air Cooling By DC Fan |
| Drop Test Result (If Applicable) | Pass |
| Weight | ~1.4 kg |
