60Volt / 10Amp / 67.2Volt (3 Pin Connector)
1. The XSTRONG POWER Charger delivers fast and reliable charging with a 60 Volt / 10 Amp / 67.2 Volt output.
2. Ideal for lithium-ion batteries. Its Automatic Battery cutt-off at 67.2 Volt prevents overcharging and extends battery life.
3. The 3 PIN Type connector ensures a secure fit for various e-scooters.
Crafted with a Durable Metal Body, the charger offers excellent heat dissipation and long-lasting use. Built-in safety features guard against overvoltage, overcurrent, and short circuits. Despite its strength, it’s lightweight and portable, making it perfect for home, office, or travel use—keeping your ride powered up wherever you are.
SCROLL DOWN FOR CHARGER SPECIFICATIONS⬇👇
Download Brochures
Download
Salient Features
Micro Controller
Based Smart SMPS Charger
Temperature Protection
Over Temperature Protection
Intelligent Charging System
CC-CV (Constant Current - Constant Voltage) charging strategy.
Battery Protection
Battery Reverse Polarity Protection
Short Circuit Protection
preventing damage to electrical components and reducing fire risk.
Voltage Protection
Over Voltage & Over Current Protection
LED Status Indicators
Bright, multicolor LED rings or panels provide intuitive status updates at a glance.
Temperature Control System
Active thermal management keeps performance stable in extreme heat or cold.
Warranty Period
1 Year Warranty
Made
"Proudly Made in India 🇮🇳"
| Input Voltages | ( Low Cut-Off : 180VAC ) & ( High Cut-Off : 280VAC ) |
|---|---|
| Input Current | 6A (±1 A) |
| AC Input Frequency | 47Hz-53 Hz |
| Peak Efficiency | >90% |
| Power Factor | 0.6 @ 230 Vac |
| Rated Power | 850W (±50 W) |
|---|---|
| Maximum DC Output Current | 10A (±1 A) |
| Maximum DC Output Power | 840 W @ 230 Vac |
| Maximum Output Voltage | 67.2V (±0.2 V) |
| Ripple | 20 mV(±10mV) - 300 mA(±10mA) |
| Line Regulation | <2% |
| Load Regulation | <2% |
| Battery Type | LITHIUM-ION |
| Over Current | >=10A+1A |
|---|---|
| Over Voltage | 67.2.0V (+0.2V) |
| Short Circuit Output | 30A |
| Over Temperature | PROVIDED |
| Reverse battery polarity | PROVIDED |
| DC Output Connector | 3 Pin Type Connector |
|---|---|
| AC Input Connector | 16A 3 PIN Inbuilt Top |
| Input Wire Length | 1500mm (±50mm) |
| Input Wire Copper | 1 SQ mm 3 CORE |
| Output Wire Length | 600mm (±50mm) |
| Output Wire Copper | 3 SQ mm 2 CORE |
| Operating Temperature | 0°C to 50°C |
|---|---|
| Humidity | 5 to 90% non-Condensed |
| Storage Temperature | 0 °C to 50 °C |
| Testing Result at %95 RH@38°C | Passed |
| Enclosure Protection | IP 21 |
|---|---|
| Dimension(L*W*H) | ~(218mmx105mmx70mm) |
| Drop Test Result (If Applicable) | PASS |
| Weight | ~1.900 Kg |
