48 Volt / 7Amp / 54.6 Volt (3 Pin Type Connector)

( 6 Reviews )

1. The XSTRONG POWER Charger delivers fast and reliable charging with a 48 Volt / 7Amp / 54.6 Volt output.

2. Ideal for lithium batteries. Its Automatic Battery cutt-off at 54.6 Volt prevents overcharging and extends battery life.

3. The 3 PIN Type connector ensures a secure fit for various e-scooters.

4. The MCU-based smart charging system monitors voltage and current to protect against overheating, overcharging, and short circuits.

Crafted with a Durable Aluminium Body, the charger offers excellent heat dissipation and long-lasting use. Built-in safety featuresguard against overvoltage, overcurrent, and short circuits. Despite its strength, it’s lightweight and portable, making it perfect for home, office, or travel use—keeping your ride powered up wherever you are.

SCROLL DOWN FOR CHARGER SPECIFICATIONS ⬇👇

Salient Features

Micro Controller

Based Smart SMPS Charger

Temperature Protection

Over Temperature Protection

Intelligent Charging System

CC-CV (Constant Current - Constant Voltage) charging strategy.

Battery Protection

Battery Reverse Polarity Protection

Short Circuit Protection

preventing damage to electrical components and reducing fire risk.

Voltage Protection

Over Voltage & Over Current Protection

LED Status Indicators

Bright, multicolor LED rings or panels provide intuitive status updates at a glance.

Temperature Control System

Active thermal management keeps performance stable in extreme heat or cold.

Input Voltages	( Low Cut-Off : 180VAC ) & ( High Cut-Off : 280VAC )
Input Current	2.5A + 0.2A
Input Frequency	50 Hz + 1%
Peak Efficiency	>83%
Switching Frequency	50 KHZ
Operating Temperature	Standard

Rated Power	350 W (± 50 W
Maximum Dc Output Current	7 A (± 0.3 A)
Maximum Dc Output Power	380 W (± 25 W)
Maximum Output Voltage	54.6V (±0.2V)
Load Regulation	<2%
Line Regulation	<2%
Battery Type	LITHIUM-ION

Over Voltage	67.2 V (+0.2V)
Over Current	>7A+1A
Short Circuit Output	Provided
Over Temperature	Provided
Reverse Battery Polarity	Provided

AC Input Connector	3 PIN Inbuilt 6A-Top
DC Output Connector	3 PIN ( T Type Connector )
Input Wire Length	1500mm (±50mm)
Input Wire Copper	0.5 SQ mm 3 CORE
Output Wire Length	1500mm (±50mm)
Output Wire Copper	1.5 SQ mm 2 CORE

Storage Temperature	0 °C to 50 °C
Operating Temperature	0 °C to 50 °C
Humidity	5 to 90% non-Condensed
Testing Result at %95 RH@38°C	PASSED

Enclosure Protection	IP 21
Dimension(LWH)	150L / 150W / 80H ±5mm
Cooling	Forced Air Cooling By DC Fan
Drop Test Result (If Applicable)	Pass
Weight	~1.4 kg
